Manufactured TIR-HK Series 12GHz-18GHz Thermal Absorbing Materials 40-60 Shore A Provide Free Sample
Gray thermal conductivity Thermal Absorbing Materials TIR-HK 40-60SHORE A 0.5-2.0mm Standard thickness
.
Company Profile
With a wide range, good quality, reasonable prices and stylish designs, Ziitek thermal conductive interface materials are extensively used in Mainboards, VGA cards, Notebooks, DDR&DDR2 products, CD-ROM ,LCD TV, PDP products, Server Power products, Down lamps, Spotlights, Street lamps, Daylight lamps, LED Server Power products and others.
Why Choose us ?
1. Our value message is'' Do it right the First time, total quality control''.
2. Our core competencies is thermal conductive interface materials
3. Competitive advantage products.
4. Condidentiality agreement Bussiness Secrect Contract
5. Free sample offer
6. Quality assurance contract
Ziitek Culture
Quality :
Do it right the first time, total quality control
Effectiveness:
Work precisely and thoroughly for effectiveness
Service:
Quick response, On time delivery and Excellent service
Team work:
Complete teamwork, including sales team, Marketing team, engineering team, R&D team, Manufacturing team, logistics team. All is for supporting and servicing a satisfy service for customers.
Certifications:
ISO9001:2015
ISO14001: 2004 IATF16949:2016
IECQ QC 080000:2017
UL
Applications:
Provide EMC material solutions for EMI & EMS issue for IT devices
1.1 Metal rubber absorber to conduct different microwave resonance frequency
within the property of loss energy
1.2 Noise suppressor for electric devices(Smart phones, Tablets, PCs and etc)
1.3 Receiver sensitivity improvement of PEN input (inductive coupling type)
1.4 Enhancement of NFC&WPC(PMA/WPC) function within electric devices
| TIR-HK Series Shielding Absorbing Materials |
| Classification | Unit | Values | Test Method |
| Color | NA | Gray | Visual |
| Specific gravity | g/cm3 | 3 | ASTM D297 |
| Surface resistance(min.) | Ω | >1 x 1012 | ASTM D257 |
| Hardness | shoreA | 40-60 | ASTM D2240 |
| Effective frequency | Hz | 12GHz-18GHz | ASTM D5470 |
| Temperature range | °C | -40 to +150 | NA |
| Storage conditions | - | 0-30°C/60%±10R.H | NA |
| Shelf life | month | 12 | NA |
| Thermal conductivity | W/mK | 0.5 | ASTM D5470 |
| Thickness | mm | 0.5mmT-2.0mmT |
| Standard size | mm | 300*300mm |
Q&A
Q: What's the thermal conductivity test method given on the data sheet ?
A: All the data in the sheet are actual tested.Hot Disk and ASTM D5470 are utilized to test the thermal conductivity.
Q: How to find a right thermal conductivity for my applications
A: It depends on the watts of power source , ability of heat dissipation. Please tell us your detailed applications and the power, so we can recommend most suitable thermal conductive materials.
Q: Do you accept custom orders ?
A:Yes , welcome to custom orders. Our custom elements including dimension , shape , color and coated on side or two sides adhesive or coated fiberglass. If you want to place a custom order , pls kindly offer a drawing or leave your custom order information .
TIR-HK(E).pdf
